Description

KEY FEATURES
• From 15,000 kg/hour
• 200 kg/minute 12,000 kg/hour 2nd cut through
4mm hole plate
• Exceptional production capacity and improved
finished product quality
• 2 Speed 22kW Mince Feedscrew Option
• Up to 21,000 kg/hr with upgraded High Efficiency
Cutting System
• Up to 12,000 kg/hr with upgraded High Efficiency
Cutting System

The key point of difference apart from improvements in our gear motor drive technology is the feedscrew and cutting
system enlargement.

The feedscrew diameter is increased to 170mm and on the HECS system this clears out to 250mm mince through an
11 inch 280mm, or 14 inch 355mm diameter plate or Unger 280mm double cut system.

The 9000 series range of mixer grinders are in line grinders whereby the feedscrew runs parallel with the mixing paddles
or right mixer grinders with the feedscrew running at right angles to the paddles similar to the 5000 series. There is no transfer screw feeding into a 2nd mincing feedscrew like the 6000 series.

This short 170mm diameter feedscrew provides much higher production output rates and with a High Efficiency Cutting System (HECS) addition the ultimate grinding system.

9000 MIXER GRINDERS have been in operation since 2013 with the most recent developments of the 92500 Right Angle Mixer Grinder (2500 kg batch capacity) and 91000 Straight Mixer Grinder.

Beyond Spectacular Production output capacity is the 9000
series Mixer Mincer/Grinder Drive Train has undergone
significant engineering upgrades.

The Thompson 9000 Mixer Mincer HECS 170-250 Mincing
System provides superior level of production output.
• Primary Cut: up to 15,000Kg - 21000Kg/Hr or 250-350 Kg/
Min through 13mm hole plate; and
• Secondary Cut: up to 12000 Kg/Hr or 200 Kg/Min through
4mm hole plate.
Production output rates are subject to Machine Specification &
Product Temperature.


9000 Series Is A New Addition To Our Mixer Grinder Range.
Key point of difference include:
• NEW Upgraded 280/11" or 355/14" “HIGH EFFICIENCY CUTTING SYSTEM” HECS:
• Feedscrew Diameter is 170mm with the “HECS” High Efficiency Cutting System Further increasing to 250mm, 280mm or 355mm Ø.
Mincing/Grinding Systems include:
• “66” Enterprise 220mm Diameter Plates.
• “U 200” Double Cut Unger System

HECS High Efficiency Cutting System Increasing from the previous 8 5/8” 220mm diameter Cutting System to:
• 11 inch Enterprise 280mm Diameter Plate.
• 14 inch Enterprise 355mm Diameter Plate.
• 280mm Diameter Unger Double or Triple Cut Mincing/Grinding System.
The 9000 series Mixer Grinders are available in both Right Angle Feedscrew Design & In Line Feedscrew Design.
• In line Mixer Grinders Short Feedscrew operates parallel with the mixing paddles.
• Right Angle Mixer Grinders Short Feedscrew operates at right angles to the paddles.
No transfer screw feeding into a Mincing/Grinding Feedscrew providing full flow production performance.
The short 170mm standard diameter feedscrew high production output rates.
HECS 11 inch 280mm or 14 inch 355mm diameter Cutting Systems achieve the ultimate grinding system.

Specifications:
• 400V, 50Hz, 3 Phase
• 66 Stainless Steel Barrel, Feedscrew, Lock Ring STD
• 11” 280mm HECS Stainless Steel Grind System Option
• 22kW Mince-Grind 2 Speed Helical Direct Drive
• 1180L Capacity to Top of Paddle 2200lb Mix Capicity
• 5 x 200Kg Bin Batch Capacity Fresh Trim
• 11kW Mix Twin Paddle Helical Direct Drive System
• Reinforced Heavy Duty Twin Stainless Steel Paddles – Counter Rotating & Overlapping
• Programmed Reciprocating Mix Cycle
• Safety Interlocked Discharge Guard with Time Out Lock
• Pneumatic Feedscrew Ejector
• Full Stainless-Steel Construction
• S/S Stand with Levelling Pads - To Discharge into 200L Bins

Additional OPTIONS INCLUDE:
• 11” 280mm High Efficiency Grind System
• 14” 355mm High Efficiency Grind System
• 30kW Mince Gear Motor Drive
• 37kW Mince Gear Motor Drive
• End Discharge Chute
• Variable Frequency Drives (VFD) Mix Paddles
• Variable Frequency Drives (VFD) Mince Feedscrew
• PLC Program Logic Control with Human Machine Interface
• Polished Bowl and Paddles
• Pneumatic Feedscrew Ejector
• Step and Platform Assembly
• Hopper Swing Guard-Interlocked
• Inspection Mirror Feedscrew Trolley Remote Control on Inspection Step
• Scale Stand
• Interlocked Guard C/W Time Out Lock
• Safety Interlock Discharge Guard with Time Out
• Bone Elimination System Pneumatic Air Purge
• Auto Reverse Feedscrew
• Feedscrew Trolley
• CO2 Bottom Cooling Injection and Top Injection through Snow Cones
• Hydraulic Operated Heavy-Duty Lid for CO2
• Light Curtains
• Plenum To Rear of Machine for CO2 Cross Flow Extraction
• Water Monitoring with PLC Control System
• Temperature Readout(Check Detail Of Existing)
• Scale Stand
• Grill Lid
• Lid Auto Release
