PSS Model SCG 200 Frozen Block Industrial Meat Grinder
PSS Model SCG 200 Frozen Block Industrial Meat Grinder
Description
The PSS Model SCG 200 Frozen Block Industrial Meat Grinder is designed with food industry operations in mind for fast grinding of any kind of fresh and frozen meat as well as whole frozen meat blocks with temperatures down to -25°C. PSS Model SCG 200 Frozen Block Industrial Meat Grinder's ensure an excellent product quality ranging from coarse to very fine grinding.The frozen meat blocks are loaded into the PSS Model SCG 200 Frozen Block Industrial Meat Grinder hopper, where they are broken by the feeding worm; this process does not create meat dust. Pre-ground material is then moved towards the PSS Model SCG 200 Frozen Block Industrial Meat Grinder's grinding head by the processing worm. A desired structure is achieved according to your choice of the final hole plate. Separate drives with freq. inverters enable an independent control of each worm.
RAM Manufacturing Equipment is located in Corona, California. We offer training, installation, service and parts for all the machines we sell. Including the PSS Model SCG 200 Frozen Block Industrial Meat Grinder and many others.
Call, E-mail or visit us today for more information!
235 Benjamin Dr. Suite 102
Corona, CA 92879
951-734-8152
bob@ramaxwell.com
Features
- All #304 Stainless Steel Construction
- Fast grinding of any kind of fresh meat and other food products
- Grinding of frozen meat blocks down to -25 °C
- Outstanding product quality for coarse as well as very fi ne grinding
- High performance and reliable operation
- Quality PSS grinding system ensures smooth grinding, minimal wear and production of premium quality products
- Easy and practical control
- Independent speed regulation of each worm
- Grinding head safety cover and maintenance safety switch
- Accessory trolley
- Rotary crane for easy manipulation
- Individual electronic and moving parts are securely covered
- Polished surfaces
- Easy and fast sanitation
- PSS BES bone elimination system
Optional Features
- PSS BES bone elimination system
- Mirror-effect polished worm
- Mirror-effect polished hopper
- Inspection platform
- Inspection platform with safety railing
- Hopper wall extensions
- Additional hopper
- Safety rail around the hopper
Specifications
| Model | SCG 200 Frozen Block Industrial Meat Grinder |
|---|---|
| Dimensions (L x W x H) | 126" x 49" x 99" |
| Grinding Worm Input | 55 kw |
| Feeding Worm Input | 11 kw |
| Machine Weight | 6,613 lbs. (3,000 kg.) |
| Fresh Meat Capacity (Fine Grinding) | 17,636 lbs./hour |
| Fresh Meat Capacity (Course Grinding) | 35,273 lbs./hour |
| Frozen Blocks Capacity (Fine Grinding) | 7,936 lbs./hour |
| Frozen Blocks Capacity (Course Grinding) | 15,873 lbs./hour |
| Grinding Set Diameter | 200 mm |
| Hopper Volume | 350 l + 220 l |
