Xuclá Model NM34AEV Bin Trolley Washing Cabinet

Xuclá Model NM34AEV Bin Trolley Washing Cabinet

Qty:

Description

Stop wasting water at your plant! Water is our most valuable commodity. Processing plants are wasting thousands of gallons each week washing bins and buggies. Let us show you how to save on water usage, reduce labor time and increase the quality of your sanitation program with our Xucla M34AEV BIN TROLLEY WASHING CABINET.
The BIN TROLLEY WASHING CABINET is all stainless steel including the stainless steel nozzles. The BIN TROLLEY WASHING CABINET M34AVE can wash up to 3,000 lbs capacity plastic bins, 2,000 lbs capacity stainless steel tubs down to 400 and 600 lbs stainless steel buggies. Production rate is approximately 20-30 units per hour. The BIN TROLLEY WASHING CABINET can also build a more compact unit if you have small size bin and buggies. Loading and unloading is a one person operation of the M34AVE Bin and Buggy washer. The water temperature can be set as high as 180° C or 365°F ensuring a maximum cleaning and sanitation with a minimal amount of water used. There are 3 cycles, per-wash, wash, and final rinse cycle

RAM Manufacturing Equipment located in Corona, California, offers training, installation, service and parts for all the machines we sell. Including the Xuclá Model NM34AEV Bin Trolley Washing Cabinet and many others. Call or visit us today for more information!

Call, Email or Visit at:
951-734-8152
235 Benjamin Dr. Suite 102
Corona, CA 92879

bob@ramaxwell.com

Features

  • PREWASHING with direct mains water
  • Water Feeding by Stainless Steel Pneumatic Angle Seat Valve of 3/4"
  • WASHING Motor Pump 20 hp
  • Stainless Steel Sprinklers
  • Motor Pump Lies within a Stainless Steel Cabinet Under the Machine
  • Dispenser Pump with a Concentration Control by Time
  • RINSING with Direct Main Water
  • Water Feeding by Stainless Steel Pneumatic Angle Seat Valve of 3/4"

Specifications

Model Model M34AVE
Washing capacity 20-30 Units per Hour
Motor 20 Hp
Water tank 120 Gallons
Voltage 230V / 60Hz / 3Ph
Dimensions with open cabinet 185"L x 94"W x 86"H
Weight 3,550 lbs

Videos

  • Bin and Buggy Washer
