Thompson Machinery Model 5000 Meat Mixer Grinder

Thompson Machinery Model 5000 Meat Mixer Grinder



The Thompson 5000 Mixer Grinder is a step up from the highly successful Thompson 4000 Series Mixer Grinder. The unique characteristics of a right-angle feed screw to the mixing bowl reduces the length of feed screw and helps to achieve a similar, high capacity production output rate like the Thompson 6000 Series Mixer Grinder.
The Thompson 5000 Mixer Grinder is a heavy duty industrial machine designed specifically for large volume mixing and grinding. The Thompson 5000 Mixer Grinder is powered by high performance motors through 2 independent helical reduction gear units.
The Thompson 5000 Mixer Grinder has the option of a “Unique Product Discharge Chute” that enables the mixing bowl to be emptied without passing through the feed screw and cutting system. Please call for more details if this interest you.
Our high efficiency cutting system is available on our Thompson mixer grinders as an option which increases production output rate by up to 100%.
• Primary cut through a ½” hole plate, up to 16,000 lbs per hour. Approximately 265 lbs per minute.
• Secondary cut through 3/16th hole plate up to 14,000 lbs per hour. Approximately 230 lbs per minute.
The labor savings achieved from these remarkable mixer - grinders, along with the high quality of the cut, produces an outstanding production savings when compared with similar competitor’s machines.
Features of the Thompson 5000 Series Mixer Grinders:
• 2 Speed feed screw operation - The 2nd speed function ensures the fastest possible production rate.
• Automatic Reversing Feed screw (optional) – The feed screw automatically and intermittently reverses during the mixing cycles to transport and lift the product out of the feed screw channel into to mixing bowl to ensure a homogenous blend.
• The 20HP helical drive delivers a more powerful performance and ensures efficient discharge while minimizing the squashing or smearing of the product.
• The segmented quick release removable stainless steel barrel assembly enables a thorough cleaning and sanitation.
• Reciprocated mixing action ensures an efficient mixing of the product.
• The counter-balanced safety interlocked grinder head cover comes complete with a viewing grill.
• The compact design only uses a 68” L x 40” W floor area, excluding barrel and any accessories.
• 56 Series cutting head.
• Low loading height.
• Smooth corners and surface finish reduces the cleaning times.
• Our Thompson mixer grinder machine bodies, grinding barrels, feed screws, grinder plate lock rings and mixing paddles are all manufactured with high quality 304 stainless steel.
• Fully seamed welded bowl is welded both inside and outside.


  • 2 Speed Grind Feedscrew Operation - The 2nd speed grinding function ensures fastest possible production rate
  • Automatic Reversing Feedscrew (optional) - Feedscrew automatically and intermittently reversing during mixing cycles to transport and eject product out of feedscrew channel into to mixing bowl to ensure homogenous blend of product batch.
  • 15kW Helical Grind Drive delivers a more powerful performance ensures efficient discharge while minimizing squashing or pulping of the product
  • Segmented Quick Release Removable Stainless Steel Barrel Assembly enables thorough cleaning and sanitation
  • Reciprocate Mixing Action ensures an efficient mix and dispensation of the product
  • Counter-balanced Safety Interlocked Domed Lid complete with viewing grills
  • Compact Design with only 67.5" x 38" of floor area required (excluding barrel and accessories)
  • 56 Series (152mm) Cutting Head Size
  • Low Loading Height
  • Smooth Corners and Surface Finish reduce cleaning down times
  • High Quality 304 Stainless Steel machine body, barrel, feedscrew, lockring and mixing paddle
  • Fully Seam Welded Bowl - Welded both inside and outside

Optional Features

  • 22kw Mince Motor
  • Variable Speed Drive
  • Unique Product Discharge Chute
  • High Efficiency Cutting System
  • Feedscrew Knife & Plate Carriage
  • e-bone / De-gristle Cutting Systems
  • Ingredients or Liquid Pouring Channel to Lid
  • Feedscrew Ejector
  • Gemini System allows 2 machines to be joined for continuous 1st and 2nd cut operation



  • Thompson 5000 Mixer Grinder
