Promarks Model VT-570 Modified Atmosphere (MAP) Tray Sealer
Promarks Model VT-570 Modified Atmosphere (MAP) Tray Sealer
Description
This machine has been discontinued. To see our current list of available tray sealers visit: https://www.rameqpt.com/collections/tray-sealing-map-skin-pack-machinesPromark’s VT-400 and VT-570 modified atmosphere (MAP) tray sealers utilizes a combination of vacuum and gas flushing to provide optimum shelf life for a wide variety of products. These modified atmosphere (MAP) tray sealing machines offer a list of standard features like Busch vacuum pumps, microprocessor control system and printed film registration system all at a price that makes them the value leader among modified atmosphere (MAP) tray sealing machines. With the addition of options like a fully validatable control system the VT-400 & VT-570 machines can be used for medical, pharmaceutical and military applications.
RAM Manufacturing Equipment located in Corona, California, offers training, installation, service and parts for all the machines we sell. Including the Promarks Model VT-570 Modified Atmosphere (MAP) Tray Sealer and many others. Call or visit us today for more information!
Call, Email or Visit at:
951-734-8152
235 Benjamin Dr. Suite 102
Corona, CA 92879
info@ramaxwell.com
Features
- All stainless-steel (#304) construction - Ease of cleaning / durable
- Busch vacuum pump - Reliability/ 2-year warranty
- PNC-01 microprocessor control - Versatile/14 recipe memory
- Automatic film advance/cut - Ease of operation
- Printed film registration system - Versatility
- Built in gas surge tank - Smooth and even gas flushing
- Auto tray lift system - Ease of tray removal
- Leveling legs - Operational stability
- Full one-year service package - Saves money
Optional Features
- Custom voltages - Versatility
- PLC/HMI control systems - Fully validatable operation
- Larger Busch vacuum pumps - Faster cycle times
- Different die sets - Versatility
- Quick change die system - Faster die changeout
Specifications
| Model | VT-400 | VT-570 |
|---|---|---|
| Vacuum Pump Capacity | 40m³/h (2Hp/2kW) | 63m³/h (3hp/2.2kw) |
| Voltage | 220V / 3PH / 60Hz / 15AMPS | 220V / 3PH / 60Hz / 20AMPS |
| Machine Weight | 913 lbs | 1,155 lbs |
| Tray Size | 11.4 " x 14.2" (Max 2 Trays) | 10.2" x 18.9" ( Max 4 Trays) |
| Tray Height | 3.5" | 3.5" |
| Max Film Diameter | OD 15.7" / ID 3" | OD 15.7" / ID 3" |
| Max Film Web | 15.7" | 18.1" |
| Machine Size L x W x H | 50" x 46" x 63" | 51" x 53" x 64" |
Videos
-
Promark’s VT-400 & VT-570 Modified Atmosphere (MAP) Tray Sealer
