Promarks Model TMC 1000 Non-Continuous Marinating Vacuum Tumbler

Promarks Model TMC 1000 Non-Continuous Marinating Vacuum Tumbler

Qty:

Description

Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumbler is a classic non-continuous marinating vacuum tumbler. The operation of the Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumbler is simple & straightforward. You simply load your product, attach the vacuum hose to the port on the outside of the drum and pull the desired vacuum then close the valve, disconnect the vacuum hose and tumble. These Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumblers are fabricated with all food grade # 304 stainless-steel and feature a safety sensor that will not allow the drum to move with the vacuum hose still attached. The standard European made DVP vacuum pump allows the Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumblers to offer high performance at a budget price.

The Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumbler are high quality, all stainless steel (# 304 food grade) machines that utilize non continuous vacuum operation. Operation is simple. Once the Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumbler is loaded with product, an external vacuum hose is connected to a vacuum port on the outside of the drum and once connected the vacuum pump is switched on allowing the drum to be evacuated. Once the desired vacuum level is reached, the valve on the vacuum port is closed, the pump is turned off, and the vacuum hose is stored back in place (safety sensor to prevent hose being pulled off machine). Then, the mixing switch is tuned on and the drum will now turn for the amount of time set on the analog timer. The Promarks TMC-1000 Non-Continuous Marinating Vacuum Tumbler present any processor with a robust and economical solution to their vacuum marinating needs.

RAM Manufacturing Equipment is located in Corona, California. We offer training, installation, service and parts for all the machines we sell. Including the Promarks Model TMC-1000 Non-Continuous Marinating Vacuum Tumbler and many others.
Call, E-mail or visit us today for more information!

235 Benjamin Dr. Suite 102
Corona, CA 92879

951-734-8152
bob@ramaxwell.com

Features

  • All # 304 food grade stainless-steel construction - Ease of cleaning / durable
  • Reverse discharge function - Ease of use
  • Analog vacuum gauge - Accurate vacuum levels
  • Analog Mixer Timer - Accurate & easy to use
  • Variable speed drum - Product versatility
  • DVP 20 European vacuum pump - High performance
  • Voltage: 110V/60HZ - Ease of operation
  • In line liquid trap - Protects the vacuum pump
  • Casters - Mobility
  • Leveling legs - Operational stability
  • Full one-year service package - Saves money

Optional Features

  • Busch vacuum pumps - Maximum performance / 2 year warranty
  • Custom Voltage - Versatility
  • Larger Busch vacuum pumps - Shorter cycle times
  • Auto-drain system liquid trap - Ease of use

Specifications

Model TMC-150 TMC-300 TMC-500 TMC-1000
Capacity 154 lbs 308 lbs 660 lbs 1,000 lbs
Vacuum Pump 20m³/h (0.9kW) 20m³/h (0.9kW) 20m³/h (0.9kW) 20 m³/h (0.9kw)
Voltage 110V/1PH/60Hz/19.54A 110V/1PH/60Hz/19.54A 110V/1PH/60Hz/19.54A 220V/60Hz/3Ph/14.8A
Machine Weight 622 lbs 661 lbs 794 lbs 1,616 lbs
Machine Dimensions L x W x H 48" x 37" x 54" 55" x 37" x 60" 55" x 37" x 63" 74" x 27" x 63"
